NU Eliot Switching Station – 345kV Switchyard
Scope: 345kV Switching Station
Location: Eliot, ME
Client: Northeast Utilities
Eliot Substation was a new greenfield station, located in Eliot, ME. This station is comprised of a 345kV switchyard, with a three-line double breaker ring bus configuration and new control house. The design for the new substation connected the existing 345kV Newington-Deerfield 307 line, located in New Hampshire, to the Central Maine Power (CMP) System.
At project completion, there were three new 345kV line terminals constructed at Eliot Substation; #307 from Deerfield, #3176 from Newington, and #3022 to Maguire Road.
Start Date: May 2012
Completion Date: December 2013
